Model Number

EE-1916VS

Dimensions

145*102MM

Dispay

VGA,HDMI, LVDS,EDP(optional)

Audio

Realtek ALC662 HD Audio decoder

Network

2 Gigabit Ethernet controller

CPU

Intel Cerelon J1900/ J1800

SOC architecture

Intel J1900/J1800

memory

1*SO-DIMM,DDR3L 1600/1333MHz Memory, Maximum support 8GB

Storage

SATA, MINI-SATA

USB

8*USB2.0

COM

6*COM Pin(COM2 support 485)

 Others

2*LAN

2*USB3.0

1*VGA

1*HDMI

1*AUDIO

1*DC

Mini-PCIE

1*MINI-SATA/1*MINI-PCIE

Chipset

AMI BIOS

Type

DC power supply mode with fan

operating temperature

-10℃-70℃

storage temperature

-20℃-80℃
