Model Number

EE-1116

Dimensions

170*170MM

Dispay

VGA(standard DB15), HDMI,LVDS(standard 30 Pin),EDP

Audio

Realtek ALC662 HD Audio decoder

Network

Gigabit Ethernet

CPU

Intel Skylake LGA1151(Support 6/7 generation processor)

Chipset

Intel H110

Memory

Single channel SO-DIMM,DDR3L 1.35V 1600/1333/1066MHz Memory, Maximum support 8GB

Storage

SATA-2.5 inch HDD, MINI-SATA SSD

USB

10*USB(2*USB3.0,8*USB2.0,  6 USB interfaces need to be expanded)

COM

6*COM(COM2 support 485)

Expansion

1*MINI-SATA,1*MINI-PCIE

Type

DC19V-10A

operating temperature

-20℃-80℃

storage temperature

-20℃-80℃
